New 24vDC Brushless Motor Power Packs

Posted on by

As we move into an age of electrification energy efficiency is becoming more important so for that reason C&C Hydraulics are launching a new range of power packs which use brushless motor technology.

The benefits of this are as follows:

  • 30% reduction in energy consumption on the same application
  • Noise reduction as there are no wearing parts the noise levels are greatly reduced
  • Improved reliability again there are no wearing parts and no starter required so very little to go wrong so the motors last a lot longer.
  • Variable operating speed, because of the brushless technology the motor speed can be varied during it’s operation to allow for soft start and finish giving greater control over the applications.

These products are ideally suited for electric vehicles and applications where reliability and noise levels are important.

The 2 models currently available are:

YBZ6Q-F2.1Y2M4-TVABN1

YBZS-E0.63Z2S103-TVXOT1

YBZS E0.63Z2S103 TVXOT1

YBZS E0.63Z2S103 TVXOT1



YBZ6Q F2.1Y2M4 TVABN1

YBZ6Q F2.1Y2M4 TVABN1

New Solar Battery Storage System installed at CC Hydraulics

Posted on by

Continuing with our environmental commitments we have now installed a 50KW battery storage system that allows the company to collect and store the solar energy that’s being generated over the weekends and days that we are not at work. This means we can be off grid for longer periods so both reducing our costs and our carbon footprint still further.

Solar Battery

solar

Environmental Commitment

Posted on by

 Resource Efficient Business (REBiz)At C&C Hydraulics we believe in playing our part in protecting our environment and reducing emissions.

As part of this principle we have enacted various upgrades to the way we operate our company.

All lighting inside the factory and offices is LED and we now use infrared heaters instead of gas, our new forklift and hydraulic lifters are all electric instead of gas and to complete the project we have just installed a 53KW solar system which will reduce the companies carbon output by an estimated 9 tons per year.

Solar Panels
53KW solar system
tipper

New 3.5T Tipper kit

Posted on by

The new 3.5T tipper kit is now more comprehensive than our previous kit and is supplied with the following components:

  • 4 stage telescopic cylinder with zinc plated outer tube
  • 12vDC power pack pre wired 2 button control & plastic cover for the electric motor
  • Pre assembled RH & LH cast steel rear hinge assemblies
  • Lower mounting bracket
  • Upper mounting bracket
  • Hose kit

Both the telescopic cylinder and power pack are more compact than the previous design so saving both space and weight.

Please see attached the data sheets which show the mounting information and the full BOM

3.5T Standard and Crew Cab Tipper Kits page 001
3.5T Standard and Crew Cab Tipper Kits page 002
3.5T Standard and Crew Cab Tipper Kits page 003
3.5T Standard and Crew Cab Tipper Kits page 004
3.5T Standard and Crew Cab Tipper Kits page 005
3.5T Standard and Crew Cab Tipper Kits page 006
3.5T Standard and Crew Cab Tipper Kits page 007
3.5T Standard and Crew Cab Tipper Kits page 008
feat img

Hydraulic Hinge Systems – Hydra Hinge

Posted on by

C&C Hydraulics have developed 2 hydraulically driven hinge systems these can be used to open and close roofs and doors on mobile or static applications.

HYDRA HINGE
The first and simplest system is the Hydra Hinge which uses a heavy duty hydraulic motor with an integral disk brake and dual counter balance valve, this drives the hinge system directly via a drive flange, the advantage of this system is it's low cost and it's simplicity and time taken to install. The system can be powered by an existing hydraulic supply from either a tractor or PTO pump or we can supply a dedicated power pack with a blue tooth remote control system which has been preconfigured and comes prewired with a potted junction box.

HYDRA HINGE 2
The second system is the Hydra Hinge 2 this uses a powerful thru rod cylinders and duplex chain to drive the hinge system, this is an offset drive with the cylinders being mounted inboard, see attached layout drawings. Again dual counterbalance valves are used to provide geometric control and lock down and the system can be driven by an existing hydraulic supply or by a our dedicated power pack and blue tooth control.
For further information please contact sales@nullcchydraulics.co.uk

Hydra Hinge Data Sheet page 001
Hydra Hinge Data Sheet page 002
Hydra Hinge Data Sheet page 003
Hydra Hinge Data Sheet page 004
Hydra Hinge Data Sheet page 005
beaver

Complete hydraulic beaver tail ramp system

Posted on by

C&C Hydraulics can now offer complete hydraulic beavertail systems for plant carrying trailers and commercial vehicles.
The hydraulic cylinder rods are produced from 431 stainless steel to prevent corrosion whilst travelling extended, the system can be operated by manual lever control valves or by blue tooth remote control.
There are 2 main systems available, the first is the traditional vertical beavertail system where the ramps rotate from a 90 degree position down to ground level, the second is the cheese wedge style beavertail where the ramps fold down level to the body of the vehicle so reducing drag on the vehicle while driving and also creating a larger platform area to load.
For more information please contact sales@nullcchydraulics.co.uk



Beaver tail kit valve controlled page 001
Beaver tail kit valve controlled page 002
Beaver tail kit valve controlled page 003
Beaver tail kit valve controlled page 004 1
Beaver tail kit valve controlled page 005
hydraulic auto spa cover

New Auto Spa Cover System

Posted on by

The first auto cover system installed on a 6m long Riptide swim spa is now commissioned and fully operational, the client has stated “ it has changed the way I use my swim spa, it is now so easy and quick to open and close the cover I can take a swim before I go work in the morning”

The new auto spa cover system has been designed and manufactured in the UK by C&C Hydraulics for more information on this revolutionary product please contact sales@nullcchydraulics.co.uk or call us on 01535 617880

hydraulic hopper

Electrically driven mobile hopper tipper Blickle

Posted on by

C&C Hydraulics have designed and produced a totally bespoke materials handling device for Liberty Steels to enable them to safely and efficiently move high value steel ingots from one process to another within their foundry.

The device was designed using the latest 3D CAD software allowing us to simulate the working conditions the machine had to meet prior to its production. Because of the very bespoke nature of the product we also used our inhouse 3D printing facility to produce the covers for the hydraulic power pack and battery / charger area and also to produce special guards to help protect the electric drive system.

The  ERGOMOVE electric drive system was supplied by Blickle and has a 1,000 kg capacity and is supplied as a plug and play system with integrated batteries. The ERGOMOVE system allows the operator to both safely and accurately manoeuvre the device into position.

 The hydraulic power pack and cylinders control the lifting and tipping function allowing the operator to collect the hopper and deposit the steel ingots into the process giving full control throughout.

cc hydraulics logo

Power tool driven hydraulic pump systems

Posted on by

The new power tool driven hydraulic pump systems from C&C Hydraulics have been developed to allow a more comfortable, convenient and cost effective solution to generating hydraulic power on a multitude of applications.

The product fits neatly in between the manual hand pumps and electrically driven power packs we already supply and offers the simplicity of the hand pump with no cables or batteries and the effortlessness of being able to press a switch to generate hydraulic power.

We can offer a variety of solutions to suit many applications, we have a comprehensive range micro gear pumps and a broad range of oil tanks. The systems can be supplied either single acting or double acting and can generate pressures of up to 250 bar.

For more detailed information please contact our sales team on sales@nullcchydraulics.co.uk

Power tool driven hydraulic pump systems
icarus icon

ICARUS blue – Live status of inputs and outputs in smartphone app

Posted on by

★ NEW: LIVE STATUS OF INPUTS AND OUTPUTS ★

We are happy to announce a powerful new feature for the ICARUS blue R-Series app, which enables the user to see the current status of the inputs and outputs LIVE at any time!

By adding this feature we not only make bidirectional communication visible to everyone, but also create new possibilities for a wide range of applications.
